Litz wire also called twist wire, stranded wire, wire rope, is made of several strands of enamelled magnet wire that twisted together. Litz Wire is used to reduce the losses caused by the skin-effect in high frequency applications. Compared with single wire in same cross section, the usage of Litz wire can reduce resistance and increase inductance, and increase the effectiveness and produce less heat. Meanwhile, Litz wire has much better mechanical flexibility.

No. of strands: From 2 up to 36000 Wire sizes: From 0.02mm up to 0.50mm Overall diameter: 0.10～10mm Cross section: ≤ 50mm² Insulation: Refer to the specifications of Enamelled wire No. of turns: From 10 up to 1200 turns/m Length of pitch: 100～0.83mm Direction of turns: Z or S

• Strands with different colors can be twisted in a specific order. • A center core can be built in to enhance the mechanical properties. • All the enamelled wires are produced by ourself, quality and delivery time can be guaranteed.

Internet connector, Audiphone, ID cards, inductive heating, magnetic components, power supply and power wireless transfer, transformer for high frequency, ultrasonic generators.
